With the Sonnet Echo 11 Thunderbolt 4 Dock, you'll be able to expand the ports of your compatible Apple M1 Mac, Apple Intel Mac with Thunderbolt 3, or Windows computer with Thunderbolt 4. The Echo 11 connects to your laptop or computer via Thunderbolt 4, which can also provide up to 90W of charging power. There are three Thunderbolt 4 ports you can use to directly attach Thunderbolt peripherals, and daisy chain up to a total of five devices. There are also three USB 3.2 Gen 2 USB Type-A ports, providing up to 10 Gb/s data transfer rate. There is a USB 2.0 Type-A port that provides charging. A 3.5mm headphone and microphone combo jack allows you to plug in a headset while the SD card slot can read SD, SDHC, and SDXC cards.
Thunderbolt 4
Thunderbolt 4 is a hardware interface that utilizes the reversible USB Type-C connector and features a maximum throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB4 at up to 20 Gb/s, and dual-bandwidth allows you to connect up to two 4K displays simultaneously or a single 8K display. Additionally, you can daisy chain up to six devices from a single Thunderbolt 4 port.
Three Thunderbolt 4 Ports for Peripherals
Connect three Thunderbolt peripherals directly (with support for daisy chaining additional peripherals). It also supports USB4 and USB 3 devices.
USB 3.2 Gen 2 Type-A Ports
The three USB 3.2 Gen 2 Type-A ports provide up to 7.5W of power each, supporting fast USB NVMe SSDs.
Support for 4K, 5K, 6K, and 8K @ 60Hz Displays
Depending on your computer, the Echo 11 supports up to two 5K displays or a single 4K, 5K, 6K, or 8K display.
Many Display Interfaces Supported
Connect Thunderbolt 3 and USB Type-C displays directly. It also supports HDMI, DP, DVI, and other displays with a Thunderbolt 3 compatible adapter (sold separately).
Charge Your Laptop
The Echo 11 provides up to 90W through the included Thunderbolt 4 cable to power and charge your laptop.
USB 2.0 Charging Port
The front panel USB 2.0 Type-A port can charge an iOS or another compatible device.
Fast SD Card Slot
Compatible with SD, SDHC, and SDXC cards, the card slot supports up to 320 MB/s read speeds and UHS-II SDXC cards.
Apple M1 Compatible
The Echo 11 is compatible with Apple M1 Mac computers.
Intel Mac Compatible
The Echo 11 is compatible with Intel Mac computers with Thunderbolt 3.
Intel Windows Compatible
The Echo 11 supports Windows computers with Thunderbolt 4.
In the Box
- Sonnet Echo 11 Thunderbolt 4 Dock
- Power Adapter
- Power Cord
- 2.3' (0.7 m) Thunderbolt 4 Cable
- Limited 2-Year Warranty
- Lifetime Technical Support
