Name: OWC Express 4M2 Four-Slot USB4 (40Gb/s) External Storage Enclosure for NVMe M.2
Brand: OWC
SKU: OWCUS4EXP4M2
Price: 599.0 AUD
Availability: InStock

Engineered to support any NVMe M.2 2230, 2242, or 2280 SSD, this compact powerhouse gives you the ultimate flexibility to choose the drive you want today—including OWC Aura SSDs with up to a massive 8.0TB capacity each. When tomorrow’s 16TB and larger drives hit the scene, you can easily boost your Express 4M2’s capacity.

High speed backups, multiple media card offloads, and intense RAW photo and 8K video editing sessions mean one thing…Heat. You can put aside any thermal throttling and noise concerns because the Express 4M2 utilizes a heat dissipating solid aluminum body along with smart, adaptive fans that activate only when needed or under heavy load. Diversity of use also means being able to easily work cross-platform with Macs and PCs. We help you keep your cool in mixed environments with our MacDrive software(sold separately).

Express 4M2 is ideal for:

DITs and Filmmakers wanting to build an affordable yet high-performance NVMe SSD RAID with up to 32TB of capacity, RAID 5 capabilities, and the ability to deliver maximum offload speeds and thermal stability when backing up media cards from multiple cameras on set.
Professional Video Editors, VFX Artists, Colorists, and High-Volume Photographers seeking an easy DIY assemble high-performance NVMe SSD RAID to handle demanding post-production and editing workflows including 8K RAW video, VFX compositing work, multicam sequences in 4K RAW or ProRes video, and batch editing ultra-high-resolution pictures.
Anyone looking for a lower cost RAID option to the award-winning four NVMe M.2 based OWC ThunderBlade and are willing to accept the Express 4M2’s larger form factor, fan cooling, no additional connectivity ports, and no ballistic shipping case for shuttle use.

OWC Express 4M2 Four-Slot USB4 (40Gb/s) External Storage Enclosure for NVMe M.2

OWC Express 4M2

The incredibly configurable, compatible, and compact DIY RAID

The Best DIY RAID You Wanted

The Power of Choice is Yours

One Cool RAID for Diverse Workflows

Express 4M2 is ideal for:

Product Specifications

Manufacturer Information

Manufacturer P/N

UPC / EAN

Customer Reviews

Added to your cart:

Device Ports	(1) Host Port - Thunderbolt 5 (USB-C) up to 80Gb/s bi-directional data speed and up to 120Gb/s display bandwidth (1) USB 3.2 Gen 2 Type-A Port up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible (3) Thunderbolt 5 (USB-C) Ports
Power Delivery	Thunderbolt 5 host port provides up to 140W of power to the host computer. Thunderbolt 5 device ports (for external drives and other devices) provide 15W of power. USB port provides up to 1.5A of power for bus-powered drives and device charging.

Display Support	Up to three 8K @ 60Hz, or two 8K @ 120Hz, or three 4K @ 144Hz
Display Support by Port	Thunderbolt 5 up to 8K @ 120Hz or three 4K @ 144Hz via a native Thunderbolt 5 display or other displays that support USB-C connections and DisplayPort 2.1

External Power Adapter	Yes
Power Supply	External UL-listed universal auto-switching power supply
AC Input	100-240V, 50/60Hz, 2.5A
DC Output	+21V, 8.58A
Wattage	180W

Security Slot	Yes
Housing Color	Chassis: Space Gray Covers: Black
Housing Material	Chassis: Aluminum Covers: Polycarbonate
Dimensions	Height: 2.2 cm (0.9 in) Length: 7.8 cm (3.1 in) Width: 17.8 cm (7.0 in)
Weight	382.0 g (0.84 lbs)
