New

11-Port OWC Thunderbolt 5 Dual 10GbE Network Dock

Name: 11-Port OWC Thunderbolt 5 Dual 10GbE Network Dock
Brand: OWC
SKU: OWCTB5DK11PD210G
Price: 949.99 AUD
Availability: InStock

SKU OWCTB5DK11PD210G

by OWC

New

$949.99 - $949.99

$949.99

$949.99 - $949.99

$949.99

Delivery time

ETA Mid January

Quantity

Shipping cost is $11.90 (flat rate) under 5kg (excluding NT).

Short-Term or One-Time Rentals?

Looking for a rental without long-term commitment? Whether you need it for a short-term stay or a one-time use, we’ve got you covered. Flexible options with selected products only. Click here for more info

Description

Simplifies Network-Based Workflows Plus Unleashes up to 20GbE for NAS and Shared Storage.

One Cable. One Dock. Complex Networking Simplified.

You can tell it’s special with just one glance. Three fully independent high speed Ethernet ports. Four Thunderbolt 5 and four USB ports. The Thunderbolt 5 Dual 10GbE Network Dock is the first all-in-one solution that simplifies complex multi-network workflows and unlocks high-bandwidth network storage connectivity while offering everyday docking convenience. Whether you’re handling audio production with Dante, routing 4K NDI video streams for broadcast, outputting large high-res files to NAS storage, or administering a cluster of virtual machines in the cloud, you can do it all through this one dock via a single cable connection to your Thunderbolt equipped Mac or PC.

Connect to Three Separate Networks

If you work in IT, media, or live production, you know the struggle of managing multiple networks with numerous adapters and tangled cables. The Thunderbolt 5 Dual 10GbE Network Dock eliminates that hassle with three independent Network Interface Cards (NICs) in one sleek solution so you can enjoy easier network isolation. Connect one 10GbE port to your NAS, the second 10GbE port to a dedicated AV network, and the front-facing 2.5GbE port to an office LAN or the internet. Each Ethernet connection runs through a uniquely addressable, fully independent dedicated NIC, so there’s no shared bandwidth allocation or security risk between them. As a result, the Thunderbolt 5 Dual 10GbE Network Dock is the only Thunderbolt dock available that lets you tailor network segmentation possibilities to your unique needs without traditional limits.

Multi-Network Versatility

Dual, fully independent 10Gb/s Ethernet ports and a front facing 2.5Gb/s Ethernet port let you connect up to three separate networks and/or high-speed network devices simultaneously

Extreme Throughput

Bond the 10GbE ports with link aggregation and access your NAS at up to 20Gb/s from your notebook computer

One Simple Solution

Easily handle complex multi-network workflows, unlock high-bandwidth network storage connectivity, and expand your connectivity possibilities with this dock and included Thunderbolt 5 cable

Greater Visual Clarity

Enhance your efficiency with sharper details by connecting up to three 8K displays¹

More Devices

Create three separate daisy chains of devices – even bus powered - and remove devices from one chain without affecting the other chains

Convenient Connectivity

Three Thunderbolt 5 and four USB 10Gb/s ports gives you the flexibility to use both cutting-edge devices and legacy gear

Transformative

Experience workstation/server-class networking from your notebook and enable workflows that were perviously cumbersome or impossible.

Silently Cool

Fanless aluminum enclosure for quiet and cool operation

Double Your Speed

When you need extreme performance, bond the dual 10GbE ports via Link Aggregation to double your network speeds to 20Gb/s…unleashing never before levels of speed from high-performance NAS setups offering two 10GbE ports, including our incredible OWC Jellyfish. Achieving these speeds used to require specialized NAS setups and expensive fiber adapters. Now, it's built right in so you can scrub through 8K+ RAW footage with zero lag or dump thousands of RAW photos to your NAS and edit straight from it with no waiting.

One To Rule Them All

In addition to advanced network capabilities and maximum storage access speeds, you can connect displays, drives, and devices with an ample variety of Thunderbolt 5 and USB 10Gb/s ports. Instead of the complexity and expense of multiple devices daisy chained together (Ethernet adapter, USB hub, etc.) the Thunderbolt 5 Dual 10GbE Network Dock gives you a single cost-effective portable solution that lets you rule your world with less.

Gigabit Ethernet Was So 2010

Most laptops and desktops have just the standard old 1GbE port—if that. The Thunderbolt 5 Dual 10GbE Network Dock cures your limited connectivity pain by giving you a glorious trinity of simultaneous, fully independent Ethernet connections and higher bandwidth through a single Thunderbolt 5 cable. Now you can instantly set up at a workstation with all networks and devices ready to go, then unplug and move with ease. No more juggling adapters or waiting for that large file to transfer. This remarkable solution transforms how you can use a laptop computer in demanding environments.

Multiple Ethernet Ports = Multiple Possibilities

You can take on nearly any IP-based workflow with the multiple and faster network connections of the Thunderbolt 5 Dual 10GbE Network Dock. Now you can integrate network-based workflows and run them simultaneously with optimum performance and simplicity. Below are just a few of the multiple possibilities (but not limited to) you can conquer:

How the Thunderbolt 5 Dual 10GbE Network Dock Improves Real World Scenarios

Live Stream / Broadcasting

Dual 10GbE ports let you dedicate one to a high-bit rate, heavy video data NDI network and the second 10GbE port to the low-latency Dante audio network each isolated on their own switches. As a result, all your video feeds and audio streams happen simultaneously and smoothly. Plus, it’s all much easier because you can integrate everything with one cable and manage video switching and audio mixing on one system instead of requiring additional computers, adapters, or complex VLAN configurations.

Professional Installers / Integrators

Modern conference rooms contain a lot of networked devices. Dual 10GbE ports let you physically separate protocols such as Dante and NDI or simply isolate network traffic for security reasons so you can connect to the corporate LAN (for internet access, Zoom/Teams calls, and general network services) with one port, while the other 10GbE port gives you an isolated AV LAN to route NDI cameras, control system, and other AV gear. Disable one NIC, change its subnet or unplug it entirely and the other won’t miss a single packet. Now with a single PC and this dock, you can easily manage a complex networked AV environment with the highest security, quality, and reliability.

3D/VFX Rendering + Separate NAS Storage

Dual 10GbE ports let you connect to your local GPU cluster and your local NAS free of bottlenecks. When rendering files, you can tap the collective power of your local render farm to significantly speed up rendering times while simultaneously loading and storing asset files on your NAS via the second 10GbE port both with full 10 Gigabit pipelines. With lightning-fast rendering and distribution of large texture files or simulation caches to each node, you can create the 3D studio of your dreams.

Enterprise Deployments

Dual 10GbE ports provide a myriad of possibilities in high-security or high-performance enterprise deployments. Connect this dock to your notebook and access a secured admin-only network with one 10GbE port and a DMZ network on the other. Your machine can also have a firewall VM on it that bridges between the two networks by leveraging the dock as the physical separation. A backup connectivity requirement is easily handled by one 10GbE port carrying normal traffic while the second port feeds a logging system or intrusion detection system with a mirror of the traffic.

Thunderbolt 5 can support up to three displays from a single computer host port dependent on the host computer's capability. This includes up to three 6K or lower resolution displays, three 8K displays @ 60Hz, or two 8K displays @ 120Hz. Presently, Apple has enabled support for a maximum of two native displays per connected Apple Mac Thunderbolt host port. Software driver based technologies, such as DisplayLink (as supported by the OWC USB-C Dual HDMI 4K Display Adapter), may enable additional display support.

Highlights:

Multi-Network Versatility: Dual, fully independent 10Gb/s Ethernet ports and a front facing 2.5Gb/s Ethernet port let you connect up to three separate networks and/or high-speed network devices simultaneously
Extreme Throughput: Bond the 10GbE ports with link aggregation and access a NAS at up to 20Gb/s from a notebook computer
One Simple Solution: Easily handle complex multi-network workflows, unlock high-bandwidth network storage connectivity, and expand connectivity possibilities with this dock and included Thunderbolt 5 cable
Transformative: Experience workstation/server-class networking from your notebook and enable workflows that were perviously cumbersome or impossible.
Convenient Connectivity: Three Thunderbolt 5 and four USB 10Gb/s ports offer the flexibility to use both cutting-edge devices and legacy gear
2 Year OWC Limited Warranty

Includes:

(1) OWC Thunderbolt 5 Dual 10GbE Network Dock
(1) 0.7M (28") Thunderbolt 5 Cable
(1) 90W External Power Supply and Power Cable
(1) Getting Started QR insert for OWC Thunderbolt 5 Dual 10GbE Network Dock
(1) Support Manual for OWC Thunderbolt 5 Dual 10GbE Network Dock (digital)
(1) OWC Dock Ejector for Mac and Windows (digital download)
(1) User Guide for OWC Dock Ejector (digital)
2 Year OWC Limited Warranty

Specifications

Specs

IEEE Specification Support	802.1AB, 802.1Qav
Device Ports	(1) Host Port - Thunderbolt 5 (USB-C) up to 80Gb/s bi-directional data speed and up to 120Gb/s display bandwidth (3) Thunderbolt 5 (USB-C) Ports (1) USB 3.2 Gen 2 Type-C Port up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible (3) USB 3.2 Gen 2 Type-A Ports up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible (2) 10 Gigabit Ethernet (10GbE) RJ45 Ports (1) 2.5 Gigabit Ethernet (2.5GbE) RJ45 Port
Power Delivery	Thunderbolt 5 device ports (for external drives and other devices) each provide 15W of power.
Display Support	Up to three 8K displays @ 60Hz or two 8K displays @ 120Hz or three 4K displays @ 144Hz
Display Support by Port	Thunderbolt 5 up to two 8K @ 120Hz or three 4K @ 144Hz via a native Thunderbolt 5 display or other displays that support USB-C connections and DisplayPort 2.1
Ethernet Speeds (RJ45)	10Gb/s (10GBASE-T) 5Gb/s (5GBASE-T) 2.5Gb/s (2.5GBASE-T) 1Gb/s "Gigabit" (1000BASE-T) 100Mb/s (100BASE-T)
Data Rate	Thunderbolt 5: up to 80Gb/s bi-directional data speed and up to 120Gb/s display bandwidth
Chipset / Controller	Thunderbolt: Barlow Ridge (JHL-9480) USB 3.2: (GL3590) USB 2.0: Fresco Logic (FL5801) 10GbE Ethernet: Marvell (AQC113) 2.5GbE Ethernet: Realtek (RTL8156B)
Host Interface Requirements	Thunderbolt 5 Thunderbolt 4 Thunderbolt 3 (Mac Only) USB4
Mac OS Compatibility	macOS 14.x Sonoma and later
PC OS Compatibility	Windows 11
Other OS Compatibility	Linux
Driver Required	Mac Users: To enable high-power USB support for the Apple Super Drive, Apple USB Keyboard, and charging for iPad 1/2/3 generation devices, please install OWC Dock Ejector for Mac. This application includes a driver that enables support for these devices and charging functions. Windows & Linux Users: Downloading and installing a Marvell driver and Realtek driver is required for enabling proper network function. Additional information available in the OWC Thunderbolt 5 Dual 10GbE Network Dock Driver Support Article.
Other Requirements	Thunderbolt 5 Mac systems require macOS 15.3.x or later. Intel based systems require macOS 15.x or later. Thunderbolt 3 support is Mac only and requires macOS 15.x or later. Linux systems require the latest version of Ubuntu.
Supports OWC ClingOn	Yes (Learn More)
External Power Adapter	Yes
Power Supply	External UL-listed universal auto-switching power supply
AC Input	100-240V, 50-60Hz, 1.5A
DC Output	+19V, 4.74A
Wattage	90W
Security Slot	Yes
Housing Color	Black
Housing Material	Aluminum
Dimensions	Height: 3.5 cm (1.4 in) Length: 21.2 cm (8.3 in) Width: 10.8 cm (4.3 in)
Weight	900.0 g (1.98 lbs)
Certifications	CE FCC RCM VCCI UKCA IC Thunderbolt
RoHS Compliant	Yes
Ambient Temperature	Operating: 32°F to 86°F (0°C to 30°C) Non-Operating: -4°F to 140°F (-20°C to 60°C)
Altitude	Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft) Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)
Humidity	Operating: 8% to 90% non-condensing Non-Operating: 5% to 95% non-condensing

Notes:

Fully compatible with 20V 90W (4.5A) power supply units.
Connected Thunderbolt and USB connected external drive solutions may remain powered on for a short duration of up to 10 minutes when the host system is asleep/powered off or when the dock/hub is physically disconnected from a system. Connected external drive solutions may get warm as they remain powered on. The temperature remains within a normal operation range and has no short or long-term effects on the device or drive.
- OWC Envoy Pro Elektron and OWC Envoy Pro FX devices remain powered on when the host system is asleep/powered off or when the dock/hub is physically disconnected from a system. These devices may get warm as they remain powered on however, the temperature remains within a normal operation range and has no short or long-term effects on the device, drive, or performance.

Additional Information

Manufacturer Information

Manufacturer P/N

TB5DK11PD210G
